MCCB Shunt Tso Tawm

Shanghai DADA Electric Co., Ltd. yog lub chaw tsim khoom lag luam txhim khu kev qha hauv Suav teb, thiab nws muaj nws tus kheej hom, CDADA. Peb nkag siab txog qhov tseem ceeb ntawm kev muaj cov khoom siv hluav taws xob muaj txiaj ntsig zoo thiab muaj txiaj ntsig uas tuaj yeem tswj tau los ntawm kev ua kom muaj kev nyab xeeb thiab kev ua haujlwm zoo. Yog vim li cas peb thiaj tsim CDADA MCCB Shunt Release, tsim tshwj xeeb kom tau raws li cov kev xav tau no.

Txawm hais tias koj yog tus kws tshaj lij nrhiav kev txhim kho koj lub cev kev nyab xeeb nta lossis tus thawj tswj kev yuav khoom nrhiav cov khoom zoo, peb cov shunt tso tawm muaj kev ntseeg siab thiab yooj yim ntawm kev siv koj xav tau.

Khoom Taw Qhia

★ Lub Hom Phiaj: Cov chaw taws teeb ua haujlwm ntawm MCCBs (Molded Case Circuit Breakers) rau kev txiav tawm tam sim.

★ Voltage Range: Tau tshaj AC 50Hz 220V / 380V thiab DC 110V / 220V khoom siv.

★ Pre-Wired Convenience: Los nrog lub Hoobkas npaj kev xaim sab hauv, tawm tsuas yog kev sib txuas sab nraud rau tus neeg siv.

★ Kev Txhim Kho Yooj Yim: Txuas koj cov kev tswj xyuas cov cim rau cov terminals uas raug xaiv - tsis muaj teeb meem nyuaj.

★ Kev Ua Tau Zoo: Tsim los rau lub luag haujlwm tam sim ntawd, ua kom lub sijhawm teb ceev ceev thaum lub sijhawm tseem ceeb.

★ Peb Cov Lus Pom Zoo: Rau qhov ua tau zoo, ib txwm phim qhov ntsuas hluav taws xob ntawm qhov shunt tso tawm nrog koj MCCB cov kev tswj fais fab mov specifications.

Technical Specifications

Installation & Usage Guide

Txhawm rau kom tau txais txiaj ntsig zoo tshaj plaws ntawm koj li CDADA MCCB Shunt Release, ua raws li cov kauj ruam no:

★ Tshawb xyuas kev sib raug zoo: Xyuas kom meej qhov ntsuas hluav taws xob ntawm qhov kev tso tawm shunt phim koj MCCB cov khoom siv tswj.

★ Txuas Kev Tswj Teeb Pom Kev: Siv lub laub khawm (SB2) los yog koj tus kheej tswj cov cuab yeej txuas mus rau terminals P3 thiab P4.

★ Kos Daim Duab Wiring: Xa mus rau daim duab kos uas tsuas yog cov kab tawg xav tau kev sib txuas los ntawm tus neeg siv-tag nrho lwm cov xov hlau yog lub Hoobkas npaj.

★ Kuaj Kev Ua Haujlwm: Ua ntej kev xa tawm tag nrho, sim cov shunt tso tawm raws li kev tswj xyuas kom paub meej tias muaj nuj nqi zoo.

★ Cov Lus Qhia Txog Kev Kho Mob: Tsis tu ncua xyuas cov kev sib txuas ntawm cov xov hlau kom pom tias hnav lossis puas. Khaws thaj chaw ib ncig ntawm lub shunt tso tawm kom huv si thiab tsis muaj plua plav kom ntseeg tau tias kev ua haujlwm ruaj khov.

Wiring Diagram Overview

Daim duab txuas rau CDADA MCCB Shunt Release yog ncaj nraim:

● SB2: Qhib lub laub khawm (muab los ntawm tus neeg siv).

● P3, P4: Cov naj npawb davhlau ya nyob twg rau kev txuas koj lub teeb liab tswj.

● Peb: Tswj fais fab mov.

● QF: Pab kev sib cuag.

Tsuas yog cov kab tawg hauv daim duab xav tau cov neeg siv kev sib txuas - tag nrho lwm yam kev xaim tsim nyog tuaj yeem txuas ua ntej los ntawm lub Hoobkas, ua rau kev teeb tsa sai thiab yooj yim dua.

Kev Ceeb Toom: Ib txwm kuaj xyuas koj cov xaim hluav taws xob ua ntej siv lub zog kom tsis txhob muaj kev phom sij.

Cov lus nug nquag

Q1: "shunt tso tawm" txhais li cas?

A1: Ib qho kev tso tawm shunt yog ib qho khoom siv siv los qhib lub qhov hluav taws xob hauv qhov hluav taws xob thaum muaj xwm txheej ceev lossis kev ua haujlwm tshwj xeeb. Nws muab txoj hauv kev kom tshem tawm hluav taws xob sai yam tsis muaj lub cev nkag mus rau lub breaker nws tus kheej.

Q2: Kuv puas tuaj yeem siv qhov kev tso tawm shunt no nrog MCCB?

A2: Tsis yog, nws yuav tsum tau sib haum nrog MCCB qauv thiab nws cov tswj voltage. Peb cov shunt tso tawm yog tsim los ua haujlwm seamlessly nrog CDADA MCCBs tab sis kuj yuav sib xws nrog lwm hom - yog tias tsis paub meej, sab laj nrog peb pab neeg txhawb nqa.

Q3: Puas yog shunt tso tawm haum rau ob qho tib si AC thiab DC daim ntawv thov?

A3: Yog lawm, peb cov shunt tso tawm txhawb nqa ob qho tib si AC (220V, 380V) thiab DC (110V, 220V) daim ntawv thov, muab kev yooj yim hla ntau qhov chaw.

Q4: Vim li cas thiaj xaiv CDADA shunt tso tawm rau lwm tus?

A4: Ntawm CDADA, peb muab qhov tseem ceeb:

● Kev Pov Hwm Zoo: Kev sim nruj ua kom txhua chav ua tau raws li cov qauv siab.

● Kev yooj yim ntawm kev teeb tsa: Cov khoom siv ua ntej siv hluav taws xob txuag lub sijhawm thiab txo qhov yuam kev.

● Kev Pab Txhawb Cov Neeg Siv Khoom: Kev pabcuam ncaj qha los ntawm peb pab neeg ua haujlwm.

● Tus Nqi-Kev Ua Tau Zoo: Tus nqi sib tw yam tsis muaj kev cuam tshuam rau qhov zoo.

Daim ntawv kawg los ntawm CDADA

Xaiv txoj cai shunt tso tawm tuaj yeem txhim kho kev nyab xeeb thiab kev ua haujlwm ntawm koj lub tshuab hluav taws xob. Nrog CDADA, koj tsis yog tsuas yog tau txais cov khoom siv xwb - koj tau txais ib tus khub cog lus rau kev ua tau zoo hauv txhua qhov kev nthuav dav. Cia peb pab koj ua tiav kev thaj yeeb ntawm lub siab nrog peb cov kev ntseeg siab thiab siv tau yooj yim.
